• Rating：0.1A 30VDC
• Contact Resistance：100mΩ Max
• Insulation Resistance：DC 500V 100MΩ Min
• Dielectric Strength：AC 250V for 1 minute
• Operation Force：200±50gf
• Operation Temperation：10℃ ~60℃
• Total Travel：2.5±0.4mm
• Operation Life：50,000 cycles
|
 |
   |
| Part Number | Rating | Contact Resistance | Insulation Resistance | Dielectric Strength | Operation Force | Operation Temperation | Total Travel | Operation Life | PDF下載 |
|---|---|---|---|---|---|---|---|---|---|
| R0193-UA-LN2 | 0.1A 30VDC | 100mΩ Max | DC 500V 100MΩ Min | AC 250V for 1 minute | 200±50gf | 10℃ ~60℃ | 2.5±0.4mm | 50,000 cycles | 暫無(wú) |
| R0193-RB-NR | 0.1A 30VDC | 100mΩ Max | DC 500V 100MΩ Min | AC 250V for 1 minute | 200±50gf | 10℃ ~60℃ | 2.5±0.4mm | 50,000 cycles | 暫無(wú) |
| R0193-RA-LN1 | 0.1A 30VDC | 100mΩ Max | DC 500V 100MΩ Min | AC 250V for 1 minute | 200±50gf | 10℃ ~60℃ | 2.5±0.4mm | 50,000 cycles | 暫無(wú) |
