• Rating：12VDC 50mA
• Travel：1.5±0.3mm
• Life：50,000 cycles
• Contact Resistance：100mΩ MAX Initial
• Insulation Resistance：100mΩ min. 100VDC
• Dielectric Strength：250VAC(50/60Hz)FOR 1MIN
• Operating Force：120±40gf
• Waterproof Grade：IP6X
|
 |
   |
| Part Number | Rating | Contact Resistance | Insulation Resistance | Dielectric Strength | Operating Force | Travel | Life | Waterproof Grade | PDF下載 |
|---|---|---|---|---|---|---|---|---|---|
| RTR-8C-G-V-B | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | 120±40gf | 1.5±0.3mm | 50,000 cycles | IP6X | 暫無(wú) |
| RTR-8T-G-V-B | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | 120±40gf | 1.5±0.3mm | 50,000 cycles | IP6X | 暫無(wú) |
